NR1507 Aluminum Nitride AlN Powder (CAS No.: 24304-00-5)

Catalog No. NR1507
Purity 99.99%/ as required
CAS Number 24304-00-5
Form White Powder
Thermal Conductivity ~150 W/m·K
Particle Size D50 = 1-5 µm (customizable from 0.5 µm to 20 µm)
Synonyms Aluminum Nitride Powder, AlN Powder
MSDS/SDS

Aluminum Nitride Powder (AlN Powder) is a light grey or white ceramic material that has a density of 3.26g/cm3. Stanford Advanced Materials (SAM) provides Aluminum Nitride Powder at a competitive price.

The estimated delivery time of 7 to 14 days applies to standard powders. For other products, delivery times may vary.

INQUIRY
Add to Compare
Aluminum Nitride Powder (CAS No. 24304-00-5)
Aluminum Nitride Powder (CAS No. 24304-00-5)
Description
Specification
SDS
Reviews

Compare Similar Items

Show Differences

This Item
Add to List
Purity
99.99%/ as required
CAS Number
24304-00-5
Form
White Powder
Thermal Conductivity
~150 W/m·K
Particle Size
D50 = 1-5 µm (customizable from 0.5 µm to 20 µm)
Synonyms
Aluminum Nitride Powder, AlN Powder

Add to List
Add to Compare
CAS Number
12033-89-5
Chemical Formula
Si3N4
Particle Size
Customized
Appearance
Grayish-white powder
Purity
≥99%
Synonyms
Silicon Nitride Powder, Si3N4 Powder

Add to List
Add to Compare
CAS Number
10043-11-5
Purity
≥99%, or customized
Chemical Formula
BN
Form
White Powder
Particle Size
1-3 μm, or customized
Synonyms
Boron Nitride Powder, BN Powder

Add to List
Add to Compare
Composition
Al2O3, SiO2, Fe2O3, Na2O, etc.
Purity
Al2O3>92%
Crystal Phase
γ-Al2O3

FAQ

Q1: What is the difference between AlN powder and Alumina (Al₂O₃) powder for thermal management?

AlN has significantly higher thermal conductivity (~150 W/m·K) compared to Alumina (~20-30 W/m·K), making it the preferred choice for high-power electronic applications where heat dissipation is critical. Both are electrical insulators, but AlN achieves better thermal performance in high-density packaging.

Q2: How should AlN powder be stored and handled to prevent hydrolysis?

AlN powder is hydrolytically sensitive and reacts with moisture to release ammonia. Store in sealed containers in a dry environment (humidity <40% recommended). For applications requiring water-based slurries, surface-treated or coated AlN powders are recommended. Always handle with gloves and a dust mask to avoid inhalation.

Q3: Can AlN powder be used in polymer composites? What loading level is typical?

Yes, AlN powder is commonly used as a thermally conductive filler in polymers, epoxies, and thermal interface materials. Typical loading levels range from 50-70 wt% depending on the desired thermal conductivity and viscosity requirements. Particle size distribution can be customized to optimize packing density and flow behavior.

Q5: Does AlN powder require surface treatment for different applications?

Yes. For applications involving water-based systems or polymer matrices, surface treatment may be required to improve hydrolysis resistance or dispersion. We offer customized surface treatment options. Please specify your application when inquiring.
